Goldeye (NEW)
收藏
品牌：Allied Vision
型号：Gigabit Ethernet
应用领域：
类别：相机
型号：Gigabit Ethernet
应用领域：
类别：相机
产品详情
| Goldeye | G-032 | | | |
| Interface | IEEE 802.3 1000BASE-T, IEEE 802.3af (PoE) | | | |
| Resolution | 636 x 508 | | | |
| Sensor | InGaAs 636 x 508 | | | |
| Sensor type | InGaAs | | | |
| Sensor size | No standard size | | | |
| Cell size | 25 μm x 25 μm | | | |
| Dark noise | 400 eˉ (low gain), 85 eˉ (high gain) | | | |
| Dark current | 370 keˉ/s @ 20 °C Sensor Temp., Cool: 63 keˉ/s @ 10 °C | | | |
| Saturation capacity | 1.9 Meˉ | | | |
| Dynamic range | 73 dB | | | |
| Lens mount | C-/F-/M42 Mount | | | |
| Max frame rate at full resolution | 100 fps | | | |
| A/D | 14 bit | | | |
| On-board FIFO | 265 MB | | | |
| | Output | |||
| Bit depth | 8-14 bit | | | |
| Mono modes | Mono8, Mono12, Mono12Packed, Mono14 | | | |
| | General purpose inputs/outputs (GPIOs) | |||
| TTL I/Os | LV TTL I/Os: 1 Input, 1 Output | | | |
| Opto-coupled I/Os | 1 Input, 2 Outputs | | | |
| RS-232 | 1 | | | |
| | Operating conditions/Dimensions | |||
| Operating temperature | -20 °C - +50 °C (Housing) | | | |
| Power requirements (DC) | 10.8 V to 30.0 V / PoE | | | |
| Power consumption (12 V) | 10.8 W @ 12 V, <12.95 W @PoE | | | |
| Mass | 360 g, Cool: 810 g | | | |
| Body Dimensions (L x W x H in mm) | 78 x 55 x 55 mm, Cool: 90 x 80 x 80 mm | | | |
| Regulations | CE, FCC Class B, RoHS | | | |
